Description
5/2 WAY DOUBLE SOLENOID VALVE OD. 8MM
VE-4V22-02PP
Datasheet
Fittings: Elbow to OD tube. 8mm
Double solenoid – 2 coils
Working pressure: 0.15-0.8 MPa
Maximum pressure: 1.2 MPa
Medium: Filtered and lubricated compressed air (40 μm)
Temperature: 5°-50°C
Electric current: 200 Milliampere (mA)
Direct current battery power DC24V
Voltage Range 10%
Power consumption: AC: 4.5VA DC: 3W
Protection class: Class F. IP65
Frequency: 5 cycles/sec
Response time: 0.05 s
