Lever Valve 5/2 Way 1/8 BSP

SKU: VE-2000-06 Categories: ,

Description

Lever Valve 5/2 Way 1/8 BSP

VE-2000-06
Datasheet

Lever valve 5 ways 2 positions.
Lever drive and spring return.
Most common application: Double acting pneumatic cylinders.
Input / Output: 1/8 BSP
Exhaust: 1/8 BSP
Fluid: filtered and lubricated compressed air (40 µm)
Pressure: 0 – 1.0 Mpa
Temperature: 0 ° C – 60 ° C
