Solenoid valve 3/2 way 1/8 BSP 24V – Mounted

SKU: Ve-3V1-01P Categories: ,

Description

Solenoid valve 3/2 way 1/8 BSP 24V – Mounted

Ve-3V1-01P: Od.6mm Plástica
Ve-3V1-02M: Od.8mm Metal.
DATASHEET

Input / Output: 1/8 BSP
Escape: 1/8 BSP
3 way solenoid valve 2 positions. Solenoid operated and spring return.
Most common application: Double Action Pneumatic Cylinders.
Single Solenoid – 1 coil
Pressure: 0.15 ~ 0.8 MPa
Maximum Pressure: 1.2 MPa
Fluid: Filtered and lubricated compressed air (40 μm)
Temperature:5ºC – 50ºC
Electrical current: 200 mA (mA)
Direct current DC24V battery power
Protection class: IP 65
Frequency: 5 CYCLES / s
Response time: 0.05 s
